The DYNAMIXEL Shield is plugged onto an Arduino UNO, Leonardo or Mega and enables the control of DYNAMIXEL servo motors with a half duplex TTL & RS485 interface. The shield is equipped with the connector system of the DYNAMXIEL X series and the protocol variants 1.0 & 2.0, allowing up to 16 motors to be connected or controlled.
Technical Data
- Dimensions: 52 x 52mm
- Supply voltage: 7.4V - 12V
- Max. Current: 1A Arduino | 10A DYNAMIXEL servo motors
Compatible development boards
Links to
Scope of delivery
- 1 x DYNAMIXEL Shield
